Shangqiu Aotewei Environmental Protection Equipment Co., Ltd. is one of the leading manufacturers and suppliers of palm oil refinery plant in China. We are committed to providing high quality customized products with competitive price. If you're going to buy ISO certified palm oil refinery plant, welcome to get quotation from our factory.
Product Name
Complete-set Medium-and-Small-Scale Continuous Palm Oil Refining & Fractionation Plant (Palm Oil Refinery Plant). It performs full-process processing including degumming, deacidification, decolorization, deodorization and fractionation for crude palm oil. It converts crude palm oil into RBD refined palm oil, palm stearin and palm olein. It is suitable for oil-refining production projects of palm-oil pressing mills and edible-oil processing enterprises. Price: 900,000 US Dollars.
| Key attributes - Vertical Distillation Equipment | ||
| 1 | Attribute | Value |
| 2 | Oil Type | Diesel |
| 3 | Phase | Three Phase |
| 4 | Voltage | Customized |
| 5 | Condition | New |
| 6 | Warranty | 1 Year |
| 7 | Raw Material) | Crude Oil, Used Ship Oil |
| 8 | Place of Origin | Henan, China |
| 9 | Brand Name | AOTEWEI |
| 10 | Name | Distillation Equipment |
| 11 | Advantages | Energy Saving, High Efficiency and Environmental Protection |
| 12 | Color | Customized |
| 13 | Function | Refined waste oil, tire‑derived oil, plastic‑derived oil, kitchen waste oil, etc. |
| 14 | Product Name | Refine equipment |
| 15 | After-sales Service Provided | Online Support |
| 16 | Type | Vacuum Filtration |
Features
Continuous degumming and deacidification unit:
The palm oil refinery plant adopts combined wet-process degumming and physical deacidification processes to remove phospholipids, free fatty acids and colloidal impurities from crude palm oil. It reduces neutral-oil loss and adapts to crude palm oil feedstock with high acid value.
Negative-pressure decolorization and filtration system:
Bleaching-earth adsorption decolorization is carried out under negative pressure, matched with closed leaf-filter equipment to efficiently remove pigments and trace impurities. Bleaching-earth consumption is controllable, and filter residues are discharged in a sealed manner.
High-temperature vacuum deodorization section:
The high-vacuum deodorization tower of the palm oil refinery plant removes odor-causing substances and peroxides in oil, improves the color and flavor of palm oil, and retains natural nutritional components of the oil.
Temperature-controlled palm-oil fractionation module:
Gradient-temperature cooling-crystallization and graded filtration realize separation of palm stearin and palm olein. The fractionation temperature range can be flexibly adjusted to produce palm-oil products of different melting points.
DCS centralized automatic control system:
Real-time data collection of temperature, vacuum degree, material level and flow rate. Automatic adjustment for key sections is realized, with interlock protection against over-temperature and low vacuum to achieve continuous and stable automatic production.
Advantage
Adaptable to crude palm oil with high acid value:
The physical deacidification process of the palm oil refinery plant delivers good processing performance for high-acid-value crude palm oil with low neutral-oil loss. It cuts alkali consumption compared with traditional chemical refining.
Diversified product portfolio:
A single set of equipment can produce refined palm oil, palm olein and palm stearin, meeting demands for edible use, food-processing and daily-chemical raw-material applications.
Vacuum sealed production for superior oil quality:
The palm oil refinery plant operates under full-process negative-pressure sealed conditions to reduce oil oxidation. Finished products feature bright color and stable flavor, complying with edible-oil quality standards.
Flexible and adjustable operation:
Process parameters for degumming, decolorization and fractionation can be adjusted according to feedstock quality. Either full-process production or independent operation of the refining or fractionation section is available.
Application Scenarios
- Supporting refining production line for palm-oil pressing mills: Crude palm oil from palm-fruit pressing is refined on-site to produce qualified refined palm oil for sales.
- Projects for medium-and-small-sized edible-oil processing plants: Purchased crude palm oil goes through refining and fractionation to produce palm-oil products with different melting points.
- Oil-processing projects for food-grade raw materials: Produce palm stearin and palm olein for manufacturers of bakery products, margarine and shortening raw materials.
- Simultaneous refining processing of palm-kernel oil: It is compatible with palm-kernel oil refining to obtain refined palm-kernel-oil products.
- Technical-renovation & upgrading for outdated oil-refining production lines: Transform old batch-type refining equipment into a continuous palm-oil refining and fractionation production line to boost production capacity and finished-product quality.
Packing & Shipping
- Tank equipment including degumming tank, deacidification reactor, decolorization tank, deodorization tower and fractionation-crystallization tank are treated with anti-corrosion and polishing. Protective cover plates are installed for all nozzle flanges. Tall tower equipment is manufactured in segments, bare-packed and fixed on transport bases with limit anti-collision reinforcement.
- Electrical-instrument and special equipment including DCS control system, vacuum unit, leaf filter, heat exchanger, regulating valve and flow meter are individually packed in shock-proof and moisture-proof solid-wood cases filled with cushioning materials. Ocean-shipping marks such as "This Side Up" and "Keep Dry" are printed on cases.
- Filter screens, sealing gaskets, valves & pipe fittings, bleaching-earth feeding assemblies and special maintenance tools are packed by category. Each package is attached with a material list for checking and acceptance upon port arrival.
- Main equipment components are split to fit 40HQ container specifications. Over-length and over-width components adopt break-bulk sea-freight. Complete packing lists and loading technical guidance are provided, and customers' on-site loading supervision is supported.
- Complete engineering documents are delivered with equipment: PID process-flow diagrams, equipment assembly drawings, pressure-vessel inspection reports, operation-maintenance manuals, spare-parts lists and supporting import-export customs-declaration documents.
FAQ
Q1: What raw materials does this plant mainly process?
A: It mainly processes crude palm oil and can also handle palm kernel oil. Solid residues shall be removed from feedstock in advance. Pre treatment is required for feedstock with excessive moisture and impurities.
Q2: What products can this plant produce?
A: It produces RBD refined palm oil. Palm olein and palm stearin can be obtained after fractionation, which can be used as edible and food industrial raw materials.
Q3: What is the processing capacity range of the equipment?
A: The daily throughput of standard models ranges from 20 200 tons. Non standard customization is supported, and capacity can be customized according to customers' raw material supply scale.
Q4: Are there any restrictions on feedstock acid value for physical refining?
A: It is suitable for crude palm oil with relatively high acid value. Process parameters need to be adjusted for feedstock with extremely high acid value, and we can provide matching process solutions.
Q5: Can the fractionation section be started or shut down independently?
A: Yes. When customers only require refining without fractionation, the fractionation module can be switched off and only the refining section runs for flexible operation.
Company Profile & Production Capacity
Shangqiu Aotewei Environmental Protection Equipment Co., Ltd. holds special-equipment manufacturing qualifications for pressure vessels. We are deeply engaged in animal-and-vegetable-oil refining and fractionation equipment, and also cover waste-oil refining and crude-oil distillation equipment sectors. We possess full capabilities for process simulation calculation, equipment design, mechanical processing, complete-set assembly and pre-delivery pressure-test commissioning.
Our company delivers full-cycle implementation for palm oil refinery plant projects, including raw-material property evaluation, customized process-package design, equipment manufacturing, factory inspection and delivery of complete technical documents. Both standard complete-set units and non-standard customization tailored to characteristics of palm-oil raw materials from different producing areas are available.
The factory owns standardized production workshops and professional engineering-technical teams. All core pressure-bearing equipment completes factory pressure testing and flaw detection. Our products are exported to many countries worldwide. We provide services including process proposals, equipment delivery, operator training and remote after-sales support to guarantee stable commissioning and operation of palm-oil-refining projects.
