Distillation Column Plant Modular complete fractionation equipment with rectification column as the core unit. It consists of full-range auxiliaries including column body, column internals, reboiler, condenser and reflux drum. It achieves separation and purification of material components relying on gas-liquid mass transfer. It can be supplied as a standalone single unit or delivered as an integrated complete process package, suitable for various projects in oil refining, chemical industry and solvent recovery. Reference Investment: 280,000 USD
| Technical Parameter of the Pyrolysis plant | |||
| 1 | Suitable Raw Materials | Waste Engine Oil, Fuel Oil, Crude Oil | Waste Engine Oil, Fuel Oil, Crude Oil |
| 2 | Structure | Horizontal Rotation Type | Horizontal Rotation Type |
| 3 | Reactor Size | φ2600×6600mm φ2800×8000mm φ3000×8800mm |
φ1500×2000mm φ1800×4000mm φ2000×600mm |
| 4 | Work Pressure | Normal Pressure | Normal Pressure |
| 5 | Oil Yield | 85%~95% | 85%~95% |
| 6 | Work Pressure | Normal Pressure | Normal Pressure |
| 7 | Power | 15-25kw/H | 15-25kw/H |
| 8 | Heating Method | Indirect Heating | Indirect Heating |
| 9 | Type of Installation | Without Foundation | Without Foundation |
| 10 | Cooling Method | Cycling Water | Cycling Water |
| 11 | Noise dB (A) | ≤ 85 | ≤ 85 |
| 12 | Cooling Method | Cycling Water | Cycling Water |
| 13 | End Product | Non-standard Diesel Oil | Non-standard Diesel Oil |
| 14 | Manpower | 4-6/shift | 2-4/shift |
Features
Optional Diversified Column Internals:
Multiple internals such as sieve trays, valve trays, structured packing and random packing are available. Selection is made according to material foaming degree, throughput and separation accuracy to satisfy diverse gas-liquid load working conditions.
Independent Reboiler-Condenser Circulation Loop:
The external reboiler generates ascending vapor inside the column, and the condenser completes vapor condensation. Matched with reflux drum for split-flow of reflux and product draw-off, the gas-liquid two-phase circulation remains stable and controllable.
Modular Segmented Column Structure:
Column sections are manufactured separately and connected by flanges for easy transportation and on-site hoisting. The number of column sections can be flexibly increased or decreased according to separation requirements to adjust theoretical plate quantity.
Custom-fabricated Column Body with Multiple Material Options:
Carbon steel, stainless steel, composite plate and lining anti-corrosion materials are optional. It adapts to working conditions of ordinary oil products, corrosive chemical solvents and acidic media.
Adaptable for Atmospheric, Slight Positive-pressure and High-vacuum Modes:
The same column body can operate under different pressures. System configuration can switch between atmospheric fractionation and negative-pressure low-temperature rectification for heat-sensitive and decomposition-prone materials.
Advantage
Flexible Configuration: Stand-alone Supply or Complete Process Package:
Either only the distillation column body, or a full process unit including heat exchange, reflux and automatic control can be provided. It fits revamping of customer's existing equipment or new-project construction.
Adjustable Separation Precision and Flexible Product Purity:
Different separation targets ranging from rough separation to high-precision purification can be realized by changing column-section height, replacing internals and adjusting reflux ratio.
Convenient Disassembly & Transportation:
Segmented column-body design eliminates transportation difficulties for over-length components. Assembly is completed via on-site flange connection, reducing heavy-cargo logistics and on-site welding workload.
Wide Operating Flexibility:
Feed flow can fluctuate within a broad range while stable separation performance is maintained under variable loads, suiting production sites with fluctuating incoming feedstock.
Convenient Operation & Maintenance: Manholes and handholes are arranged on each column segment. Operators can directly enter the column for inspection, cleaning and replacement of packing or trays without cutting the column vessel as a whole.
Application Scenarios
- Revamping & Upgrading of Oil Refinery Projects: Add or replace distillation columns for existing units to improve oil fractionation precision and upgrade product quality.
- Purification Process for Fine Chemical Industry: Serve as the post-treatment step in fine-chemical production to separate reaction mixtures, remove impurities and obtain qualified high-purity target products.
Packing & Shipping
The distillation column is delivered in separate column segments. Large column sections go through sandblasting and anti-corrosion treatment and are firmly secured inside 40HQ, FR (Flat-Rack) or OT (Open-Top) containers. Column internals (packing, trays), reboilers, condensers, instruments, valves and sealing parts are packed in moisture-proof, rust-proof and vacuum-sealed wooden cases. Packing list, equipment dimension-and-weight sheets, assembly drawings, PID process flow diagrams, material certificates, pressure-vessel certificates and full-set customs-clearance documents are available. Multiple trade terms including EXW, FOB and CIF are supported to guarantee intact cross-border ocean transportation.
FAQ
Q1: What determines the separation performance of the distillation column plant?
A: It mainly depends on theoretical plate number, type of column internals, reflux ratio and inherent composition of feed materials. Provide parameters of material samples in the early stage, and we will carry out process calculation to confirm column height and internals selection.
Q2: Can I purchase only the column body instead of the whole system?
A: Yes. We can supply column body and internals separately. Customers can connect with their existing reboilers, condensers and control systems for on site matching.
Q3: Is on site installation of column equipment difficult?
A: Equipment segments are connected by flanges; only bolt alignment and tightening are required. Hoisting instruction documents are provided for large size components, and our technicians can be dispatched for on site assembly and commissioning guidance.
Q4: What kinds of materials are unsuitable for processing in distillation columns?
A: Materials prone to polymerization and coking, or feedstock containing large amounts of solid particles require a pre treatment filtration unit at the feed inlet to avoid blockage of column internals.
Q5: What parameters are required in the early stage for solution design?
A: Feed composition, processing capacity, target product purity, operating pressure (atmospheric / vacuum) and material corrosiveness are required for completing process and equipment design of the distillation column.
