Rubber Pyrolysis Plant
Rubber Pyrolysis Plant is a modular complete rubber pyrolysis unit. Different from standalone machines, it integrates pyrolysis reactor, full oil-gas treatment, carbon black collection and tail-gas purification into one integrated system without separate component assembly. It mainly processes waste tires, rubber blocks, rubber scraps and waste rubber products. Under high-temperature oxygen-free conditions, it cracks feedstock into fuel oil, steel wires and carbon black. Featuring unit-based integration with minimal on-site assembly work, it fits medium-scale rubber solid-waste disposal projects for medium-sized recycling enterprises, regional solid-waste treatment agencies and overseas medium-size investment projects.
Price Note: This is a modular integrated complete set. Final price depends on batch processing capacity, carbon-black collection grade, condensing unit specification and environmental-protection configuration. Reference starting price for standard unit: USD 45 000 / set, excluding ocean freight, civil construction and on-site installation & commissioning. Itemized quotation is available according to customer's raw-material type and capacity requirements.
| Technical Parameter of the Pyrolysis plant | |||
| 1 | Suitable Raw Materials | Rubber/Plastic Products etc | Rubber/Plastic Products etc |
| 2 | Structure | Horizontal Rotation Type | Horizontal Rotation Type |
| 3 | Reactor Size | φ2600×6600mm φ2800×8000mm φ3000×8800mm |
φ1500×2000mm φ1800×4000mm φ2000×600mm |
| 4 | Capacity for One Batch | 8-10Mt; 12-15Mt; 18-20Mt | 1Mt; 3Mt; 5Mt |
| 5 | Oil Yield from Tyres | 38%~45% | 38%~45% |
| 6 | Work Pressure | Normal Pressure | Normal Pressure |
| 7 | Reactor Rotation Speed | 0.4R/M | 0.4R/M |
| 8 | Fuels Choice | Coal, Wood, Gas, Oil | Coal, Wood, Gas, Oil |
| 9 | Power | 15~22kw/h | 8~15kw/h |
| 10 | Cooling Method | Cycling Water | Cycling Water |
| 11 | Type of Drive | External Annular Gear | External Annular Gear |
| 12 | Heating Method | Direct Heating | Direct Heating |
| 13 | Type of Installation | Without Foundation | With Foundation / Integrated Base |
| 14 | Noise dB (A) | ≤ 85 | ≤ 85 |
| 15 | Operating Mode | Intermittent Operation | Intermittent Operation |
| 16 | Total Weight (MT) | 25~50 | 10~25 |
Features
① Modular integrated design for factory-preassembled modules to reduce on-site welding. Condensing, carbon-black recovery and tail-gas treatment are built as independent pre-assembled modules. Only pipeline connection is required after site delivery, greatly cutting on-site construction work.
② Negative-pressure closed carbon-black conveying structure to lower dust leakage risk. Pyrolysis-generated carbon black is transported via sealed negative-pressure pipelines to collection units without open discharging, effectively restraining carbon-black dust diffusion and improving workshop working conditions.
③ Combined condensing-heat-exchange structure adapted to heavy-oil fractions from rubber pyrolysis. Shell-and-tube plus coil combined condenser provides sufficient heat-exchange area for efficient heavy-oil capture and reduces oil product loss.
④ Gas pressure-stabilizing safe gas-supply system to ensure stable furnace combustion. Pyrolysis flammable gas is equipped with pressure-stabilizing, dewatering and tar-removal filter units for stable gas pressure and complete combustion, avoiding safety hazards caused by gas pressure fluctuation.
⑤ Multi-point real-time temperature & pressure monitoring with over-limit alarm protection. Multiple temperature and pressure sensors are installed for real-time operating-parameter monitoring. Automatic alarm triggers for over-temperature and over-pressure to improve equipment safety performance.
Advantages
① Complete modular supply to avoid component-matching difficulties.
All systems are delivered as one package. Separate auxiliary-equipment procurement is not required, eliminating poor component compatibility and shortening project commissioning cycle.
② Low on-site workload for faster project commissioning. Pre
-fabricated modules require mainly on-site pipeline connection. Installation and commissioning time is much shorter compared with scattered-part equipment.
③ Negative-pressure closed carbon-black conveying for user-friendly working environment.
Carbon black is fully conveyed under closed negative pressure with little workshop dust, improving operator conditions and complying with workshop safety production requirements.
④ Comprehensive safety monitoring system for controllable operation risks.
Real-time temperature-pressure monitoring & alarm together with multi-layer safety protection reduce faults caused by mis-operation with moderate technical requirements for operators.
Application Scenarios
- - Medium-sized tire recycling enterprises: Regionally process waste automobile and truck tires to recover tire oil, steel wires and carbon black.
- - Renewable-resource processing plants: Harmless and resource-oriented disposal of rubber solid waste for sale of output products.
- - Supporting disposal unit for industrial parks: Undertake volume-reduction treatment of rubber-based waste inside industrial parks.
Packing & Shipping
Packing:
Main reactor is anti-rust & anti-corrosion treated and wrapped with heavy-duty waterproof tarpaulin. Heavy-duty modules for condensation, carbon-black collection and tail-gas treatment are bare-packed. Electric control cabinet, sensors and other precision electrical parts are packed in shock-proof moisture-resistant plywood crates. Valves, seals, pipeline parts and wearing spares are packed in export wooden cases and pallets. Documents supplied: Pressure-vessel inspection report, assembly drawings, operation & maintenance manual, safety operation procedure, packing list.
Shipping:
Standard-size modules are loaded into 40HQ containers. Over-dimension reactor sections are shipped by break-bulk vessel. Heavy-duty flat-bed trucks deliver goods to project site for inland transportation.
Lead Time:
85-120 working days upon deposit receipt. Lead time is extended for custom high-capacity and upgraded environmental-protection configurations. Real-site photos and videos are provided for customer confirmation before shipment.
FAQ
Q1: What is the difference between Rubber Pyrolysis Plant and rubber pyrolysis machine?
A: Rubber pyrolysis machine generally refers to a basic standalone unit whose auxiliary parts need extra selection by customers. Rubber Pyrolysis Plant is a modular integrated complete system with fully integrated oil gas, carbon black and environmental protection units. Only pipeline connection is required for commissioning.
Q2: What is the maximum batch capacity of this unit?
A: Standard model handles 1 6 tons per batch. Reactor volume can be customized to adjust batch feeding capacity.
Q3: What workshop requirements does the equipment have?
A: Ventilated workshop with hardened anti seepage floor is required. Dust proof protection for carbon black discharging area and circulating cooling water supply are needed.
Q4: Can distillation equipment be added later to refine tire oil?
A: Yes. Oil gas output ports are reserved for later connection with distillation units to convert crude tire oil into heavy fuel oil.
Q5: Does the gas system need extra pressure boosting equipment?
A: The unit comes with built in pressure stabilizing and filtering units. No extra booster is needed under normal conditions. Booster assemblies are optional for high altitude sites.
Q6: Is a shredder included in standard configuration?
A: Shredder is not included in standard scope and is available as an optional module upon customer request.
